Power Amplifiers
DA8.4
4-Channel Class-D Power Amplifier, 2000W per Channel @ 4Ω
- 4 × 2000W at 4Ω
- Stable 2Ω Operation
- Up to 4 × 5500W in Bridged Mode
- Stereo, Mono, and Bridge Operating Modes
- Selectable 38dB, 35dB, 32dB. and 29dB gain
- Universal Switch-Mode Power Supply
- Temperature-controlled Cooling
- Comprehensive Protection Circuitry
Overview
The Sound Barrier DA8.4 is a high-power four-channel Class-D amplifier engineered for professional systems that require substantial output and flexible multi-channel configuration. It delivers 4 × 2000W at 4Ω and 4 × 1350W at 8Ω, making it a versatile choice for subwoofers, full-range loudspeakers, stage monitors, and multi-speaker systems in touring productions, nightclubs, live venues, houses of worship, and fixed installations.
Its compact 1U architecture supports stereo, mono, and bridge operation, with selectable 38dB, 35dB, 32dB, and 29dB gain settings. The amplifier supports minimum loads of 2Ω per channel in stereo or mono operation and 4Ω in bridge mode, with burst output up to 4 × 2800W at 2Ω or 2 × 5500W bridged at 4Ω.
A universal switch-mode power supply with active Power Factor Correction provides efficient, stable performance across a worldwide AC input range. Front-to-rear temperature-controlled cooling and protection against undervoltage, DC output, over-temperature, overload, and short circuit help deliver dependable performance in demanding professional applications.
KEY FEATURES
- 4 × 2000W at 4Ω
- Stable 2Ω Operation
- Up to 4 × 5500W in Bridged Mode
- Stereo, Mono, and Bridge Operating Modes
- Selectable 38dB, 35dB, 32dB. and 29dB gain
- Universal Switch-Mode Power Supply
- Temperature-controlled Cooling
- Comprehensive Protection Circuitry
Universal Power with Active PFC
The DA Series features a universal switch-mode power supply designed to operate from 100–240 VAC ±10%, 50/60Hz, allowing reliable use across a wide range of global power systems. Active Power Factor Correction (PFC) optimizes current draw, improves power efficiency, and helps maintain consistent amplifier performance under demanding operating conditions.
3 Year Warranty
Includes a 1-year standard limited warranty, extended to 3 years total at no additional cost when the product is registered within 90 days of purchase. Proof of purchase is required. Statutory consumer rights are not affected.
Specifications
Output Power
- 2Ω Stereo:
- 4 x 2800W
- 4Ω Stereo:
- 4 x 2000W
- 8Ω Stereo:
- 4 x 1350W
- 4Ω Bridge:
- 2 x 5500W
- 8Ω Bridge:
- 2 x 4000W
- 16Ω Bridge:
- 2 x 2500W
Amplifier Specifications
- Output Channels:
- 4
- Topology:
- Class D
- Efficiency:
- Greater than 80%—up to 90% under laboratory conditions
- Operating Modes:
- Stereo / Mono / Bridge
- Minimum Load:
- Stereo / Mono: 2Ω
- Minimum Load:
- Bridge: 4Ω
- Frequency Response:
- 20Hz–20kHz, +0 / -0.5dB
- THD+N:
- Typical 0.01% at 8Ω and 10% rated power
- Damping Factor:
- Typical 5000 at 8Ω, 20Hz–200Hz
- Crosstalk:
- ≥90dB, 20Hz–1kHz below rated power
- Input Impedance:
- 20kΩ balanced / 10kΩ unbalanced
- Input Sensitivity:
- 1.13V / 1.59V / 2.25V / 3.17V RMS selectable
- Selectable Gain:
- 38dB / 35dB / 32dB / 29dB
Input / Output Section
- Input Connectors:
- 4 x balanced XLR inputs
- Output Connectors:
- 4 x speakON-type NL4
Power Requirements
- Nominal AC Input:
- 100–240 VAC ±10%, 50/60Hz
- Power Supply:
- Universal switch-mode power supply with active PFC
- Standby Power:
- 160W
Cooling & Protection
- Cooling:
- Front-to-rear airflow with temperature-controlled fans
- Protection Circuits:
- Undervoltage, DC, over-temperature, overload, and short circuit
Construction
- Rack Space:
- 1U
- Dimensions (W x H x D):
- 19.02 × 1.77 × 14.57 in (483 × 45 × 370 mm)
- Net Weight:
- 20.9 lb (9.5 kg)
Warranty
- 3-Year Warranty:
- 3-Year Warranty with Product Registration
