DC360

Overview

The Sound Barrier DC360 is a professional heavy-duty swivel clamp designed for connecting 2-inch / 50mm truss tubes or pipes while providing full 360° rotational adjustment. Its swivel design makes it well suited for angled truss configurations, complex stage structures, lighting systems, and other installations where flexible positioning between two sections of truss or pipe is required.

The DC360 features full wrap-around clamp bodies designed to provide secure engagement around the tubing. Dual M10 clamping bolts with oversized wing nuts allow each side of the clamp to be tightened securely while providing convenient installation, adjustment, and removal in demanding production environments.

Rated for loads up to 1,100 lbs. / 500 kg, the DC360 is engineered for professional use and is TÜV certified, meeting recognized international safety and quality standards through independent TÜV testing. Its combination of high load capacity, adjustable positioning, and heavy-duty construction makes it ideal for touring productions, concert stages, rental inventories, houses of worship, corporate events, exhibition systems, and permanent installations.

KEY FEATURES

• Heavy-duty 360° swivel clamp
• Designed for 2" / 50mm truss tubing
• Full 360° rotational adjustment
• 1,100 lb / 500 kg maximum load capacity
• Dual M10 clamping bolts
• Oversized wing-nut fasteners
• Adjustable-angle truss connections
• TÜV certified
