ST29210

Overview

The Sound Barrier ST29201 is a professional F34 square truss segment built for applications requiring reliable structural support, frequent assembly, and efficient transportation. Measuring 3.28 ft (1 meter) in length, it provides a compact modular building block for lighting grids, goalpost systems, exhibition structures, stage installations, and other production configurations.

The ST29201 is manufactured from high-strength 6082 aluminum, combining structural durability with the reduced weight needed for mobile and touring applications. Four 50 mm main chords with 2 mm wall thickness provide a solid foundation, while 20 mm diagonal bracing reinforces the truss section throughout its length.

A genderless conical coupling system aligns adjoining truss sections precisely while helping maintain rigidity at each connection point. This design allows systems to be assembled and disassembled quickly using simple hand tools, making the ST29201 especially practical for rental companies, touring productions, mobile entertainers, and production teams working under tight setup schedules.

Its standard 290 × 290 mm F34 format integrates with Sound Barrier truss components and accessories of the corresponding size and connection type, allowing larger systems to be configured from straight sections, corners, base plates, spacers, and mounting accessories.

From temporary event structures to permanent entertainment installations, the ST29201 provides the strength, flexibility, and consistent fitment required by professional production environments.

KEY FEATURES

• 3.28 ft / 1 m straight truss segment
• TUV Certified Welding
• High-Strength 6082 Aluminum
• 50 mm Main Chords
• 2 mm Wall Thickness
• 20mm Reinforced Diagonal Bracing
• Conical Coupling System
• Connection Hardware Included
