DA9.2

2-Channel Class-D Power Amplifier, 5000W per Channel @ 4Ω

  • 2 × 5000W at 4Ω
  • Stable 2Ω Operation
  • Up to 1 × 13,000W at 4Ω in bridge mode
  • Stereo, Mono, and Bridge Operating Modes
  • Selectable 41dB, 38dB, 35dB, and 32dB gain
  • Universal Switch-Mode Power Supply
  • Temperature-controlled Cooling
  • Comprehensive Protection Circuitry
Where to Buy
DA9.2
DA9.2

Overview

The Sound Barrier DA9.2 is a high-power two-channel Class-D amplifier engineered for professional loudspeaker systems that need substantial output in a compact rack format. It delivers 2 × 5000W at 4Ω and 2 × 3000W at 8Ω, making it well-suited to high-output subwoofers, full-range loudspeakers, stage monitors, and demanding sound-reinforcement systems in touring productions, nightclubs, live venues, houses of worship, and fixed installations.

Its compact 1U architecture supports stereo, mono, and bridge operation, with selectable 41dB, 38dB, 35dB, and 32dB gain settings. The amplifier supports minimum loads of 2Ω per channel in stereo or mono operation and 4Ω in bridge mode, with burst output up to 2 × 6500W at 2Ω or 1 × 13000W bridged at 4Ω.

A universal switch-mode power supply with active Power Factor Correction provides efficient, stable performance across a worldwide AC input range. Front-to-rear temperature-controlled cooling and protection against undervoltage, DC output, over-temperature, overload, and short circuit help deliver dependable performance in demanding professional applications.

KEY FEATURES

  • 2 × 5000W at 4Ω
  • Stable 2Ω Operation
  • Up to 1 × 13,000W at 4Ω in bridge mode
  • Stereo, Mono, and Bridge Operating Modes
  • Selectable 41dB, 38dB, 35dB, and 32dB gain
  • Universal Switch-Mode Power Supply
  • Temperature-controlled Cooling
  • Comprehensive Protection Circuitry

Universal Power with Active PFC

The DA Series features a universal switch-mode power supply designed to operate from 100–240 VAC ±10%, 50/60Hz, allowing reliable use across a wide range of global power systems. Active Power Factor Correction (PFC) optimizes current draw, improves power efficiency, and helps maintain consistent amplifier performance under demanding operating conditions.

Universal Power with Active PFC

3 Year Warranty

Includes a 1-year standard limited warranty, extended to 3 years total at no additional cost when the product is registered within 90 days of purchase. Proof of purchase is required. Statutory consumer rights are not affected.

3 Year Warranty

Specifications

Output Power

2Ω Stereo:
2 × 6500W
4Ω Stereo:
2 × 5000W
8Ω Stereo:
2 × 3000W
4Ω Bridge:
1 × 13,000W
8Ω Bridge:
1 × 10,000W
16Ω Bridge:
1 × 6000W

Amplifier Specifications

Output Channels:
2
Topology:
Class D
Efficiency:
Greater than 80%
Operating Modes:
Stereo / Mono / Bridge
Minimum Load Stereo / Mono:
2Ω
Minimum Load Bridge:
4Ω
Frequency Response:
20Hz–20kHz, +0 / -0.5dB
THD+N:
Typical 0.01%
Damping Factor:
Typical 5000 at 8Ω, 20Hz–200Hz
Crosstalk:
≥90dB, 20Hz–1kHz below rated power
Input Impedance:
20kΩ balanced / 10kΩ unbalanced
Input Sensitivity:
1.38V / 1.95V / 2.75V / 3.89V RMS selectable
Selectable Gain:
41dB / 38dB / 35dB / 32dB
Output RMS Voltage:
154.8V RMS

Input / Output Section

Input Connectors:
2 x balanced XLRF inputs
Link Outputs:
2 x parallel XLRM inputs
Output Connectors:
2 x speakON-type NL4

Power Requirements

Nominal AC Input:
100–240 VAC ±10%, 50/60Hz
Power Supply:
Universal switch-mode power supply with active PFC
Standby Power:
130W

Cooling & Protection

Cooling:
Front-to-rear airflow with temperature-controlled fans
Protection Circuits:
Undervoltage, DC, over-temperature, overload, and short circuit
Limiter Functions:
Undervoltage, DC, over-temperature, overload, and short circuit

Construction

Rack Space:
1U
Dimensions (W x H x D):
19. x 1.8 x 18.3 inches (483 x 45 x 465mm)
Net Weight:
29 lb (13kg)

Warranty

3-Year Warranty:
3-Year Warranty with Product Registration
