Power Amplifiers

DA15.2

2-Channel Class-D Power Amplifier, 7500W per Channel @ 4Ω

  • 2 × 7500W at 4Ω
  • Stable 2Ω Operation
  • Up to 1 × 18,000W at 4Ω in bridge mode
  • Stereo, Mono, and Bridge Operating Modes
  • Selectable 41dB, 38dB, 35dB, and 32dB gain
  • Universal Switch-Mode Power Supply
  • Temperature-controlled Cooling
  • Comprehensive Protection Circuitry
Where to Buy
DA15.2
DA15.2

Overview

The Sound Barrier DA15.2 is a high-power two-channel Class-D amplifier engineered for professional audio systems requiring exceptional output from a compact rack space. Delivering 2 × 7500W at 4Ω and remaining stable down to 2Ω per channel, it is ideal for powering large-format subwoofers, high-output full-range loudspeakers, and demanding speaker systems used in touring productions, nightclubs, festivals, live venues, houses of worship, and large-scale installations.

Its compact 1U chassis supports stereo, mono, and bridge operation, with bridged output reaching up to 1 × 18,000W at 4Ω. Selectable gain and corresponding input-sensitivity settings allow the amplifier to integrate easily with professional DSP processors, mixing consoles, and loudspeaker-management systems. A universal switch-mode power supply with active Power Factor Correction provides efficient, stable operation across varying AC power conditions.

Front-to-rear airflow with temperature-controlled fans helps maintain reliable performance during extended high-output operation. Comprehensive protection circuitry safeguards the amplifier and connected loudspeakers against undervoltage, DC, over-temperature, overload, and short-circuit conditions.

KEY FEATURES

  • 2 × 7500W at 4Ω
  • Stable 2Ω Operation
  • Up to 1 × 18,000W at 4Ω in bridge mode
  • Stereo, Mono, and Bridge Operating Modes
  • Selectable 41dB, 38dB, 35dB, and 32dB gain
  • Universal Switch-Mode Power Supply
  • Temperature-controlled Cooling
  • Comprehensive Protection Circuitry

Universal Power with Active PFC

The DA Series features a universal switch-mode power supply designed to operate from 100–240 VAC ±10%, 50/60Hz, allowing reliable use across a wide range of global power systems. Active Power Factor Correction (PFC) optimizes current draw, improves power efficiency, and helps maintain consistent amplifier performance under demanding operating conditions.

Universal Power with Active PFC

3 Year Warranty

Includes a 1-year standard limited warranty, extended to 3 years total at no additional cost when the product is registered within 90 days of purchase. Proof of purchase is required. Statutory consumer rights are not affected.

3 Year Warranty

Specifications

Output Power

2Ω Stereo:
2 × 8500W
4Ω Stereo:
2 × 7500W
8Ω Stereo:
2 × 4000W
4Ω Bridge:
1 × 18,000W
8Ω Bridge:
1 × 15,000W
16Ω Bridge:
1 × 8000W

Amplifier Specifications

Output Channels:
2
Topology:
Class D
Efficiency:
Greater than 80%
Operating Modes:
Stereo / Mono / Bridge
Minimum Load Stereo / Mono:
2Ω
Minimum Load Bridge:
4Ω
Frequency Response:
20Hz–20kHz, +0 / -0.5dB
THD+N:
Typical 0.01%
Damping Factor:
Typical 5000 at 8Ω, 20Hz–200Hz
Crosstalk:
≥90dB
Input Impedance:
20kΩ balanced / 10kΩ unbalanced
Input Sensitivity:
1.65V / 2.33V / 3.30V / 4.66V RMS selectable
Selectable Gain:
41dB / 38dB / 35dB / 32dB
Output RMA Voltage:
178.9V RMS

Input / Output Section

Input Connectors:
2 x balanced XLRF inputs
Link Outputs:
2 x parallel XLRM inputs
Output Connectors:
2 x Neutrik® speakON® NL4

Power Requirements

Nominal AC Input:
100–240 VAC ±10%, 50/60Hz
Power Supply:
Universal switch-mode power supply with active PFC
Standby Power:
150W

Cooling & Protection

Cooling:
Front-to-rear airflow with temperature-controlled fans
Protection Circuits:
Undervoltage, DC, over-temperature, overload, and short circuit
Limiter Functions:
Undervoltage, DC, over-temperature, overload, and short circuit

Construction

Rack Space:
1U
Dimensions (W x H x D):
19. x 1.8 x 18.3 inches (483 x 45 x 465mm)
Net Weight:
29 lb (13kg)

Warranty

3-Year Warranty:
3-Year Warranty with Product Registration
